Aircraft Comparison
DJI Matrice 4 vs Matrice 5: What’s Changed and Which One Fits Your Operation?
Compare Matrice 5TD with the Matrice 4 series for Canadian operations: thermal imaging, zoom, aircraft temperature ratings, automated mapping and pilot-flown field work.
Remote Robotic · October 14, 2026 · 12 min read
DJI has launched the Matrice 5TD, the first aircraft in its Matrice 5 generation. It’s built exclusively for the new DJI Dock 4 and brings major upgrades in thermal imaging, zoom, range, AI and cold-weather performance.
The Matrice 4 series is still very much in the picture. It covers pilot-flown models for field crews and dock models for automated operations, including a dedicated mapping drone that the Matrice 5 lineup doesn’t yet have.
This guide compares the Matrice 4 series and the Matrice 5TD so you can decide which fits your operation in Canada.
The short answer
- Choose the Matrice 5TD for 24/7 automated operations that need the best thermal imaging, longest zoom and range, more advanced AI and operation down to –40°C.
- Choose the Matrice 4D for automated, survey-grade mapping from a dock.
- Choose the Matrice 4TD for automated thermal and security work where a lighter Dock 3 installation or vehicle mounting makes more sense.
- Choose the Matrice 4E or 4T when your crews fly in the field with a controller.
The Matrice 4 and Matrice 5 lineups
| Model | How it’s flown | Main role |
|---|---|---|
| Matrice 4E | Pilot with controller | Mapping and surveying |
| Matrice 4T | Pilot with controller | Thermal inspection, public safety, search and rescue |
| Matrice 4D | Automated, from DJI Dock 3 | Automated mapping and visual inspection |
| Matrice 4TD | Automated, from DJI Dock 3 | Automated thermal, night and security work |
| Matrice 5TD | Automated, from DJI Dock 4 | Continuous thermal, security, public safety and infrastructure monitoring |
The Matrice 5TD is designed for docked, remote operations. It supports the DJI RC Plus 2 only as an emergency controller, with basic flight and live video. It isn’t a replacement for the pilot-flown Matrice 4E or 4T.
Matrice 5TD vs Matrice 4TD: head-to-head
The Matrice 4TD is the most direct comparison, since both are thermal dock drones.
| Feature | Matrice 4TD | Matrice 5TD |
|---|---|---|
| Dock | DJI Dock 3 | DJI Dock 4 |
| Turnaround between flights | About 27 min (recharge in dock) | Under 45 s (battery swap) |
| Weight | About 1.85 kg (2.09 kg max takeoff) | 2.6 kg (3.05 kg max takeoff) |
| Max flight time | 54 min | 59 min |
| Max hover time | 47 min | 55 min |
| Max speed | 21 m/s | 21 m/s |
| Aircraft operating temperature | –20°C to 50°C | –40°C to 50°C |
| Weather rating | IP55 | IP55 |
| Wide camera | 1/1.3", 48 MP | 1/0.98", 50 MP, f/1.8 |
| Medium tele | 70 mm, 48 MP | 70 mm, 50 MP |
| Tele | 168 mm, 48 MP | 252 mm, 50 MP |
| Max hybrid zoom | 112× | 176× |
| Thermal resolution | 640×512 (super-resolution 1280×1024) | 1280×1024 native (UHR 2560×2048) |
| Thermal sensitivity | Not specified in the same terms | ≤50 mK |
| Laser rangefinder | 1.8 km | 3 km |
| NIR auxiliary light | Yes | Yes |
| Onboard AI | 3 target categories | 17 target types |
| Obstacle sensing | Vision, plus LiDAR and radar module | Built-in vision, rotating LiDAR, mmWave radar and downward 3D infrared |
| Video transmission | O4+ Enterprise, up to 25 km (FCC) | O4 Enterprise Enhanced, up to 40 km (IC, Canada) |
| Cellular | Optional dongle | Dual built-in 4G modules |
| Speaker | AS1, 300 m | AS2D, 400 m, 120.5 dB |
| Light | AL1 spotlight, 100 m | AL2D, 40 W spotlight and 18 W floodlight |
| Parachute | Third-party | DJI AP1, top mount |
What the Matrice 5 improves
1. Thermal imaging
The Matrice 5TD’s native 1280×1024 thermal sensor doubles the Matrice 4TD’s native resolution. Its ultra-high-resolution mode reaches 2560×2048. It also adds:
Sensitivity of 50 mK or better, for picking up smaller temperature differences
Two measurement ranges: –40°C to 150°C in high gain, and 0°C to 550°C in low gain
Visible and thermal image fusion
Spot and area temperature measurement and temperature alerts
Sun burn protection for the thermal sensor
Up to 32× thermal digital zoom
Why it matters: you can see smaller hot spots from further away. That covers electrical connections, substation components, flare stacks, pipelines, conveyor idlers and people or vehicles at night.
2. Zoom and detail
Wide camera: a 1/0.98", 50 MP sensor with an f/1.8 aperture for better detail and low-light performance
Tele camera: a 252 mm equivalent lens, up from 168 mm, with up to 176× hybrid zoom
Night Scene Mode: ISO up to 1,638,400 for colour imaging in very low light
Lens defogging: on all three visible cameras
Why it matters: you can read gauges, inspect insulators, check bolts and identify vehicles from a safer distance.
3. Range and measurement
Laser rangefinder: up to 3 km, compared with 1.8 km
Video transmission: up to 40 km under Canada’s IC standard
Max flight distance: 53 km
Multi-dock missions: the drone can take off from one Dock 4 and land at another up to 15 km away
4. Smarter AI
Onboard AI expands from three categories to 17 target types. These include:
People and vehicles, with colour filtering
Smoke and fire
Livestock
Trucks, buses, forklifts and excavators
River debris
Combined with DJI FlightHub 2’s AI route generation and change detection, this makes automated monitoring much more useful for security, public safety, construction and industrial sites.
5. Cold-weather performance
The Matrice 5TD operates from –40°C to 50°C, compared with –20°C to 50°C for the Matrice 4TD. Its battery also heats itself in low temperatures. This is one of the most important upgrades for Canadian operators.
6. Endurance
Flight time goes up to 59 minutes, and hover time to 55 minutes, compared with 54 and 47 minutes on the Matrice 4D and 4TD. Longer hover time matters for overwatch, security incidents and live inspections.
7. Built-in obstacle sensing
On the Matrice 4D series, the LiDAR and radar obstacle sensing comes as a separate module. On the Matrice 5TD, it’s built in. The system includes:
Omnidirectional vision sensing
Rotating LiDAR with up to 110 m range
Millimetre-wave radar that can detect a 12 mm cable up to 40 m ahead
A downward 3D infrared sensor for precise landings
8. Connectivity
Dual built-in 4G modules give the drone a backup link alongside its main transmission system. That’s useful at remote sites and in areas with obstructed signals.
9. Upgraded accessories
AS2D speaker: 120.5 dB with a 400 m broadcast range
AL2D light: a 40 W spotlight and an 18 W floodlight in one unit
AP1 parachute: DJI’s own parachute, mounted on top
Where the Matrice 4 series still wins
Survey-grade mapping
The Matrice 4E (pilot-flown) and Matrice 4D (docked) both have a 4/3", 20 MP wide camera with a mechanical shutter. It’s built for survey-grade photogrammetry without ground control points. These are still the right drones for:
Stockpile volumetrics
Construction progress and earthworks
Orthomosaics and 3D models
Mine planning and site surveys
The Matrice 5 generation doesn’t have a dedicated mapping model yet.
Pilot-flown field operations
The Matrice 4E and 4T are compact, portable drones that crews fly with a controller. They suit:
Search and rescue
Police and fire response
Field inspections
Survey crews moving between sites
The Matrice 5TD is designed for dock-based operations only.
Lighter, more flexible deployment
The Matrice 4D and 4TD run on DJI Dock 3. Compared with Dock 4, Dock 3:
Weighs 55 kg instead of 66 kg
Draws up to 800 W instead of 2,000 W
Connects to the network directly, without a separate ground station
Supports vehicle-mounted deployment
Lower weight and cost of entry
The Matrice 4 series is lighter and has been on the market longer. That means more established workflows, accessories and support.
Which drone fits your industry?
| Industry or use case | Best fit |
|---|---|
| Security and alarm response | Matrice 5TD |
| Public safety and drone as first responder | Matrice 5TD (docked), Matrice 4T (field crews) |
| Oil and gas thermal monitoring | Matrice 5TD |
| Substation and power line inspection | Matrice 5TD |
| Pipeline and corridor patrols | Matrice 5TD |
| Extreme-cold and northern sites | Matrice 5TD |
| Mining stockpiles and pit mapping | Matrice 4D (docked), Matrice 4E (pilot-flown) |
| Construction progress and volumetrics | Matrice 4D (docked), Matrice 4E (pilot-flown) |
| Search and rescue | Matrice 4T (pilot-flown), Matrice 5TD (docked coverage) |
| Mobile or temporary sites | Matrice 4D or 4TD on a vehicle-mounted Dock 3 |
| Sites with limited power | Matrice 4D or 4TD on Dock 3 |
Many organizations will run a mix: the Matrice 5TD for continuous thermal and security coverage, the Matrice 4D for automated mapping, and the Matrice 4E or 4T for field crews.
Frequently asked questions
What is the DJI Matrice 5TD?
It’s DJI’s first Matrice 5 generation aircraft, built for automated operations from DJI Dock 4. It features a 1280×1024 thermal camera, a 252 mm tele camera, a 3 km laser rangefinder and 59 minutes of flight time.
Is there a pilot-flown Matrice 5?
Not at launch. The Matrice 5TD is designed for Dock 4 and supports the DJI RC Plus 2 only as an emergency controller.
Does the Matrice 5TD replace the Matrice 4TD?
For high-demand thermal and security operations, it’s a major upgrade. The Matrice 4TD on Dock 3 is still a strong choice where a lighter installation, lower power draw or vehicle mounting matters.
Which is better for mapping, Matrice 4 or Matrice 5?
The Matrice 4E and 4D. Their mechanical-shutter 4/3" camera is built for survey-grade mapping.
How much better is the Matrice 5TD thermal camera?
It has a native 1280×1024 sensor, double the Matrice 4TD’s 640×512, with an ultra-high-resolution mode of 2560×2048 and sensitivity of 50 mK or better.
Which handles Canadian winters better?
The Matrice 5TD, rated to –40°C. The Matrice 4D and 4TD are rated to –20°C, and the pilot-flown Matrice 4E and 4T to –10°C.
Can the Matrice 5TD fly from Dock 3?
No. The Matrice 5TD works with DJI Dock 4, and the Matrice 4D and 4TD work with DJI Dock 3.
Get started
Not sure which drone fits your sites? Talk to our team and we'll recommend the right aircraft for each location, or a mix of both generations, built around your operations.
