Unitree

B2

Regular price: $140,000.00 CAD
Sale price: $140,000.00 CAD
Regular price

Up to 5 hours of operation

IP67 Rated

120 kg payload capacity

6 m/s speed

Operating temperature: -20°c - 55°c

LiDAR & RGB camera

The B2 brings unmatched industrial-grade mobility to your operations. With speed exceeding 6 m/s, climbing ability over 45°, and a platform that supports heavy payloads (up to 120 kg standing), B2 is built for demanding missions—whether it’s inspection, logistics, remote terrain operations or rugged environments. With legged locomotion, optional wheeled configuration, and advanced perception modules, this platform offers flexibility, endurance and adaptability like few others.

UNITREE B2 — SPECIFICATIONS

Physical Characteristics

Size (Standing): 1098 mm × 450 mm × 645 mm
Size (Lying Prone): 880 mm × 460 mm × 330 mm
Weight: 60 kg (total, battery included)

Power System

Battery Performance: 45 Ah (2250 Wh), 58 V
Battery Life: 4 – 6 hours

Walking without load > 5 hours, > 20 km mileage
Walking with 20 kg load > 4 hours, > 15 km mileage

Wheeled Foot: Optional

Payload & Mobility

Maximum Load (Standing): 120 kg
Maximum Load (Walking): > 40 kg
Continuous Stair Climbing: Stairs of 20 – 25 cm
Single Obstacle Crossing: Climb up and down stairs of 40 cm (forward direction)
Operating Temperature: –20 °C to 55 °C
Maximum Climbing Angle: > 45 °
Running Speed: > 6 m/s (speed limit applies for security purposes)
Ditch Jumping Width: 0.5 – 1.2 m
Maximum Jump Distance: > 1.6 m

Environmental Protection

Ingress Protection: IP67 (dustproof and water-resistant)

Control & Perception

Computing Options:

Intel Core i5 × 1
Intel Core i7 × 3
NVIDIA Jetson Orin NX × 1
(varies with configuration)

Sensing Sensors

3D LiDAR × 1
Depth Camera × 2
Optical Camera × 2
(sensor layout varies by configuration)

Interfaces

Network Interface: 1000 M Base Ethernet × 4
USB Ports: USB 3.0 × 4
Power Outputs: 12 V × 4, 5 V × 1, 24 V × 4, BAT × 1

Note:

Certain features (such as maximum speed and advanced autonomy) require specific configurations or secondary development.
Actual performance may vary based on terrain, payload, and environmental conditions.

Remote Robotic is a North American authorized dealer for Unitree B2.

Your purchase includes the full standard manufacturer warranty, and we also offer optional support programs to help protect your equipment and keep it performing at its best.

Learn more about Extended Care Program

B2 SDK Development guide

We offer training for all robotic solutions

Learn more

B2 FAQ

B2 is designed for heavy-duty environments—industrial inspection, infrastructure patrol, logistics over uneven terrain, even remote/harsh sites. With its high mobility, heavy payload capacity and dual leg/wheel options, it offers flexible field readiness

Yes — with a heavy payload budget (standing 120 kg) and support for various configurations (leg + wheel, rugged terrain), B2 supports custom sensor modules, cameras, LiDAR, robotic arms, etc. Ensure total payload + robot weight remains within spec and check connector/interface options.

The wheeled-leg variant adds wheels to each leg, improving efficiency on flat surfaces while retaining legged mobility for obstacles. This enables hybrid mission profiles: legged for stairs/complex terrain, wheeled for speed/efficiency.
