DJI Avata 2 – Full Specifications
Aircraft
Takeoff Weight
Approx. 377 g
Dimensions
185 × 212 × 64 mm (L × W × H)
Max Ascent Speed
6 m/s (Normal Mode)
9 m/s (Sport Mode)
Max Descent Speed
6 m/s (Normal Mode)
9 m/s (Sport Mode)
Max Horizontal Speed (near sea level, no wind)
8 m/s (Normal Mode)
16 m/s (Sport Mode)
27 m/s (Manual Mode)*
*Limited to 19 m/s in EU regions.
Max Takeoff Altitude
5000 m
(Measured in windless conditions with a 500 m vertical climb.)
Max Flight Time
Approx. 23 minutes
(Tested at 21.6 kph, windless, sea level.)
Max Hovering Time
Approx. 21 minutes
(Tested at sea level in windless conditions.)
Max Flight Distance
13 km
(Tested at 43.2 kph in windless conditions.)
Max Wind Resistance
10.7 m/s (Level 5)
Operating Temperature
-10° to 40° C (14° to 104° F)
GNSS
GPS + Galileo + BeiDou
Hovering Accuracy
Vertical: ±0.1 m (vision), ±0.5 m (GNSS)
Horizontal: ±0.3 m (vision), ±1.5 m (GNSS)
Internal Storage
46 GB
Class
C1 (EU)
Camera
Image Sensor
1/1.3-inch CMOS, 12 MP effective
Lens
FOV: 155°
Equivalent focal length: 12 mm
Aperture: f/2.8
Focus range: 0.6 m to ∞
ISO Range
Auto: 100–25600
Manual: 100–25600
Shutter Speed
Video: 1/8000–1/30 s
Photo: 1/8000–1/50 s
Max Photo Resolution
4000 × 2256 (16:9)
4000 × 3000 (4:3)
Photo Mode
Single shot
Format: JPEG
Video Resolution
4K (4:3): 3840 × 2880 @ 30/50/60 fps
4K (16:9): 3840 × 2160 @ 30/50/60/100 fps
2.7K (4:3): 2688 × 2016 @ 30/50/60 fps
2.7K (16:9): 2688 × 1512 @ 30/50/120 fps
1080p (4:3): 1440 × 1080 @ 30/50/120 fps
1080p (16:9): 1920 × 1080 @ 30/50/120 fps
Video Format
MP4 (H.264/H.265)
Max Video Bitrate
130 Mbps
File System
exFAT
Color Modes
Standard
D-Log M
Field of View Modes
Normal
Wide-angle
Ultra-wide-angle
EIS (Electronic Image Stabilization)
Supports RockSteady 3.0+ and HorizonSteady
Stabilization can be disabled*
*When disabled, wide-angle footage supports Gyroflow for offline stabilization.
Gimbal
Stabilization
Single-axis mechanical tilt gimbal
Mechanical Range
Tilt: -95° to 90°
Controllable Range
Tilt: -85° to 80°
Max Tilt Speed
100°/s
Angular Vibration Range
±0.01°
Electronic Roll Axis
Real-time screen correction unavailable during recording
Correction applies to recorded footage
Sensing System
Sensing Type
Downward and backward vision system + downward ToF
Downward Sensing
ToF measurement height: 10 m
Precise hovering: 0.3–10 m
Measurement range: 0.3–20 m
FOV: 78° (H) × 78° (V)
Backward Sensing
Measurement range: 0.5–20 m
FOV: 78° (H) × 78° (V)
Operating Requirements
Diffuse, patterned surfaces
Reflectivity >20%
Lighting >15 lux (normal indoor lighting)
Video Transmission
System
O4 Video Transmission
Live View Quality
Up to 1080p/30/50/60/100 fps
Operating Frequencies
2.400–2.4835 GHz
5.170–5.250 GHz*
5.725–5.850 GHz*
*Use depends on local regulations.
Transmitter Power (EIRP)
2.4 GHz: <33 dBm FCC, <20 dBm CE/SRRC/MIC
5.1 GHz: <23 dBm CE
5.8 GHz: <33 dBm FCC, <30 dBm SRRC, <14 dBm CE
Communication Bandwidth
Up to 60 MHz
Max Transmission Distance (Unobstructed)
FCC: 13 km (limited by aircraft flight distance)
CE: 10 km
SRRC: 10 km
MIC: 10 km
Max Transmission Distance (With Interference)
Strong (urban): 1.5–4 km
Medium (suburban): 4–10 km
Low (seaside): 10–13 km
Max Transmission Distance (Obstructed)
Buildings: 0–0.5 km
Trees: 0.5–3 km
Max Download Speed
Wi-Fi: up to 30 MB/s
(Measured in controlled conditions.)
Lowest Latency (with DJI Goggles 3)
1080p/100fps: ~24 ms
1080p/60fps: ~40 ms
Max Video Bitrate
60 Mbps
Antennas
4 antennas, 2T4R
Wi-Fi
Protocols
802.11 a/b/g/n/ac
Operating Frequency
2.400–2.4835 GHz
5.725–5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <20 dBm
5.8 GHz: <20 dBm FCC/SRRC, <14 dBm CE
Bluetooth
Protocol
Bluetooth 5.0
Operating Frequency
2.400–2.4835 GHz
Transmitter Power (EIRP)
<10 dBm
Intelligent Flight Battery
Capacity
2150 mAh
Weight
Approx. 145 g
Standard Voltage
14.76 V
Max Charging Voltage
17 V
Battery Type
Li-ion
Energy
31.7 Wh @ 0.5C
Charging Temperature
5° to 40° C
Charging Time
Using 60W Charging Hub:
• 0–100%: approx. 45 minutes
• 10–90%: approx. 30 minutes
Direct charging (30W):
• 0–100%: approx. 88 minutes
• 10–90%: approx. 60 minutes
Charger
Recommended Chargers
DJI 65W Portable Charger
DJI 65W Car Charger
USB Power Delivery chargers
Battery Charging Hub
Input
5–20 V, up to 3 A
Output (Power Accumulation)
Up to 65 W
Output (Charging)
Up to 17 V
USB Output
5 V, 2 A
Charging Type
Charges 3 batteries sequentially
Compatibility
DJI Avata 2 Intelligent Flight Battery
Storage
Supported microSD Cards
Kingston Canvas Go! Plus: 64GB / 128GB / 256GB / 512GB
Lexar Professional 1066x: 64GB / 128GB / 256GB / 512GB
DJI FPV Remote Controller 3
Max Operating Time
Approx. 10 hours
Operating Temperature
-10° to 40° C
Charging Temperature
0° to 50° C
Charging Time
Approx. 2 hours (5V, 2A)
Battery Capacity
2600 mAh
Weight
Approx. 240 g
Dimensions
165 × 119 × 62 mm
Operating Frequency
2.400–2.4835 GHz
Transmitter Power (EIRP)
2.4 GHz: <26 dBm FCC, <20 dBm CE/SRRC/MIC
