Aircraft
42.5 kg (without battery)
65 kg (with two DB2000 batteries)
95 kg (with cargo at sea level）
2200 mm
1590 x 1900 x 947 mm
(LxWxH) (arms unfolded, propellers folded)
2800x3085x947 mm
(LxWxH) (arms & propellers unfolded)
1115x760x1027 mm
(LxWxH) (arms & propellers folded)
Towards body
- Loadable Battery Quantity
2
- Hovering Endurance (empty weight, with max battery capacity)
29 mins (dual battery mode)
15 mins (single battery mode)
*The data was collected in controlled conditions: zero altitude and a windless environment. For reference only.
- Hovering Endurance (max weight, with max battery capacity)
18 mins (30 kg weight load, dual battery mode)
8 mins (40 kg weight load, single battery mode)
*The data was collected in controlled conditions: zero altitude and a windless environment. For reference only.
- Max Flight Distance (empty weight, with max battery capacity)
28 km (dual battery mode)
12 km (single battery mode)
*The data was collected in controlled conditions: zero altitude and windless environment, at a constant speed of 15m/s. For reference only.
- Max Flight Distance (max weight, with max battery capacity)
16 km (30 kg weight load, dual battery mode)
8 km (40 kg weight load, single battery mode)
*The data was collected in controlled conditions: zero altitude and windless environment, at a constant speed of 15 m/s. For reference only.
- Max Flight Time (max weight, with max battery capacity)
18 mins (30 kg weight load, dual battery mode)
9 mins (40 kg weight load, single battery mode)
*The data was collected in controlled conditions: zero altitude and a windless environment, at a constant speed of 15 m/s. For reference only.
-20° to 45° C
- Ingress Protection Rating
IP55
- Hovering Accuracy (with strong GNSS signal)
- RTK positioning enabled:
±10 cm horizontal, ±10 cm vertical
RTK positioning disabled:
±60 cm horizontal and ±30 cm vertical (radar enabled: ±10 cm) - RTK/GNSS Operating Frequency
- RTK: GPS L1/L2, Galileo F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
GNSS: GPS L1, BeiDou B1I, Galileo F1, Galieo E1, QZSS L1 - Max Pitch Angle
- 30°
- Max Ascent Speed
- 5 m/s
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload. For reference only.
3 m/s (vertical)
5 m/s (tilted)
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload. For reference only.
- Max Horizontal Speed: 20 m/s
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload, for reference only. - Max Flight Altitude
- 6000 m (without payload)
- Max Wind Speed Resistance
- 12 m/s
*The data was collected in controlled conditions: zero altitude and a windless environment, with a 30 kg payload. For reference only.
Propulsion System
100x33 mm
48 rpm/V
4000 W/rotor
Carbon fiber composite
54 inch
Foldable double-blade propellers
1375 mm
8
LED Light
- Effective Illumination Distance
10 m
60 Hz, automatically switch on according to ambient light
DJI O3 Image Transmission
Pigeon (with DDR)-2T4R
- Signal Effective Distance
20 km (FCC)
8 km (CE/SRRC/MIC)
*Measured with FCC compliance in unobstructed environments with typical interference. Data is for reference only. The actual transmission distance may vary depending on the environment's obstruction and interference conditions. Please pay attention to reminders in the app.
2.4000 to 2.4835 GHz
5.725 to 5.850 GHz
*Some countries or regions do not support the 5.8 GHz frequency band. Please refer to local flight laws and regulations for details.
2.400 GHz - 2.4835 GHz:
<33 dBm（FCC）
<20 dBm（CE/SRRC/MIC）
5.725 GHz - 5.850 GHz：
<33 dBm（FCC）
<30 dBm（SRRC）
<14 dBm（CE）
AES-256
Supported
Forward and Backward Active Phased Array Radar
RD241608RF (forward)
RD241608RB (backward)
Fixed altitude range: 1.5-200 m
Sensible distance (rear): 1.5-50 m
FOV Forward: 360° horizontal, ±45° vertical，±45°upward
Backward: ±45° horizontal, 360° vertical
Operating conditions: Available during takeoff, landing, and ascending when an obstacle is more than 1.5 m away from the aircraft
Safe distance: 3.5 m (distance between the propeller tip and obstacle when the aircraft is hovering after braking)
Sensing direction: multi-direction
Binocular Vision System
Horizontal: 90; Vertical: 106°
- Work Environment Requirements
Normal lighting with clearly textured surfaces
FPV Camera
1920x1440
149°
30fps
Full HD FPV Single Axis Gimbal Camera
Cargo Case
754x472x385 mm (LxWxH)
573x416x305 mm (LxWxH)
EPP plus aluminum alloy frame
- Weighing Feature
- Supported
- Weight
Approx. 3 kg
0-40 kg
Parachute
≤ 95 kg
300x200x120 mm (LxWxH)
Approx. 2.1 kg
Approx. 1000 ms
≤ 6 m/s (at sea level, no wind)
Square
Nylon
Approx. 22 ㎡
60 m
-20° to 45° C
- Ingress Protection Rating
IP55
- Mainboard Power-off Battery Life
≥ 1 hour
Real-time record for 10 flights
- Buzzar Alarm
- Supported
- Lighting Alarm
Supported
Supported
- Automatic Opening
- Supported
Winch System (Optional)
A2EWI-30A
252x195x193 mm (LxWxH)
2.5 kg (without clump and couple)
1.9 kg
0.6 kg
- Touchdown Release Feature
- Supported
- Payload Capacity
5-30 kg (dual battery)5-40 kg (single battery)
20 mMax Retraction Speed
- 0.8 m/s
- Operating Temperature
- -20° to 45° C
- Ingress Protection Rating
- IP55
- Weighing Function
- Supported
- Cut Cable Protection
- Supported
- Swing Control Feature
- Supported
- Manual Operation
- Supported
- Automatic Operation
- Supported
- Deceleration Protection
- Supported
DJI DB2000 Intelligent Battery
- Model
- DB2000
- Capacity
- 38000 mAH
- Nominal Voltage
- 52.22 V
- Type
- 14S1P
- Energy
- 1984.4 Wh
- Weight
- Approx. 11.3 kg
- Installation Method
- Plug
- Dimension
- 316x152x279 mm (LxWxH)
- Operating Temperature
- -20° to 45° C
- Charging Rate
- 5 to 15° C: 1.0C15 to 45° C: 2.5C
- Max Charging Power
- 5700 W
- Automatic Heating Feature
- Supported (when the battery temperature is below 10° C, pressing and holding the button or turning on the drone will activate the self-heating function. When the battery temperature is below 20° C, connecting the charger to the battery will activate the self-heating function. Charging and discharging in a low-temperature environment may reduce the battery's lifespan)
DJI C8000 Intelligent Charger
- Model
- CHX101-7000
- Input
- 90-264 V AC
- Output
- 42-59.92 V DC
- Max Output Power
- 7200 W (Dual input)3600 W (Single input)
- Output Channel Quantity
- 2
- Protection Feature
- The feature is designed to respond to issues including overheating, overvoltage, undervoltage, short circuits, fan stalls, etc.
- Operating Temperature
- -20° to 45° C
- Charging Security
- Connector protection feature available
Remote Controller
- Type
- DJI RC Plus
- APP
- DJI Pilot 2
- Operating Frequency
- 2.400-2.483 GHz
5.725-5.850 GHz - EIRP
- 2.400-2.4835 GHz:
<33 dBm（FCC）
<20 dBm（CE/SRRC/MIC）
5.725-5.850 GHz:
<33 dBm（FCC）
<23 dBm（SRRC）
<14 dBm（CE） - Operating Temperature
- -20° to 50° C
- Charging Environment Temperature
- 5° to 40° C
- Built-in Battery Life
- 3.3 hours
- External Battery
- 2.7 hours
- Charging Method
- Use a USB-C fast charging charger with a maximum power of no less than 65 W (maximum voltage of 20 V). A DJI portable charger is recommended.
- Charging Time
- 2 hours with built-in battery, 2.5 hours with built-in and external battery (shutdown status according to official charging method)
- Ingress Protection Rating
- IP54
- Video Output Interface
- HDMI
- Wi-Fi Protocol
- Wi-Fi 6
- Wi-Fi Working Frequency
- 2.4000-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz - Bluetooth Protocol
- Bluetooth 5.1
- Bluetooth Working Frequency
- 2.4000 - 2.4835 GHz
- EIRP
- <10 dBm
- GNSS
- GPS+Galileo+BeiDou
- Screen
- 7.02 inch touch LCD display screen, resolution 1920*1200, brightness 1200 nits
- Dual Operator Mode
- Supported
