DJI Neo 2 – Full Specifications
Aircraft
Takeoff Weight
151 g (without DJI Neo 2 Digital Transceiver)
160 g (with DJI Neo 2 Digital Transceiver)
Weight may vary depending on materials and environmental factors.
Dimensions
147 × 171 × 41 mm (with propeller guards, without transceiver)
167 × 171 × 54 mm (with propeller guards, with transceiver)
Max Ascent Speed
0.5 m/s (Cine Mode)
3 m/s (Normal Mode)
5 m/s (Sport Mode)
(Measured in open, windless environments; for reference only.)
Max Descent Speed
0.5 m/s (Cine Mode)
3 m/s (Normal Mode)
3 m/s (Sport Mode)
Max Horizontal Speed
8 m/s (Normal Mode)
12 m/s (Sport Mode)
12 m/s (Tracking Mode)
Max Takeoff Altitude
2000 m
(Measured in windless conditions from 2000 m altitude.)
Max Flight Time
Approx. 19 minutes
Approx. 17 minutes with propeller guards installed
Each battery supports at least 20 palm takeoff-and-land cycles during continuous filming.
(Tested without transceiver; results vary.)
Max Hovering Time
Approx. 18 minutes
16.5 minutes with propeller guards
(Tested at sea level in windless conditions.)
Max Flight Distance
7 km
(Tested at constant 9 m/s with camera set to 1080p/30fps.)
Max Wind Resistance
10.7 m/s (Level 5)
Operating Temperature
-10° to 40° C (14° to 104° F)
GNSS
GPS + Galileo + BeiDou
Hovering Accuracy
Vertical: ±0.1 m (vision), ±0.5 m (satellite)
Horizontal: ±0.3 m (vision), ±1.5 m (satellite)
Internal Storage
49 GB
Class
C0 (EU)
Camera
Image Sensor
1/2-inch CMOS
Lens
FOV: 119.8°
Equivalent focal length: 16.5 mm
Aperture: f/2.2
Focus distance: 0.7 m to ∞
ISO Range – Photo
100–3200 (Single Auto)
100–12800 (Burst Auto / Timed Auto)
100–12800 (Manual)
ISO Range – Video
100–12800 (Auto and Manual)
Shutter Speed
Video: 1/8000–1/30 s
Photo: 1/8000–1/10 s
Max Image Size
4000 × 3000 (4:3)
4000 × 2250 (16:9)
Still Photography Modes
Single shot (12 MP)
Timed shot (12 MP, 2–60 s)
Photo Format
JPEG
Video Resolution – Horizontal Shooting
4K (4:3): 3840 × 2880 at 60/50/30 fps
1080p (4:3): 1440 × 1080 at 60/50/30 fps
4K (16:9): 3840 × 2160 at 100*/60/50/30 fps
1080p (16:9): 1920 × 1080 at 100*/60/50/30 fps
*100 fps supported only with motion or remote control.
Vertical Shooting
2.7K (9:16): 1512 × 2688 at 60/50/30 fps
Video Format
MP4
Max Video Bitrate
80 Mbps
File System
exFAT
Color Mode
Normal
Electronic Image Stabilization
Supports RockSteady
Stabilization can be turned off when using goggles
Footage without stabilization supports Gyroflow for offline stabilization.
Gimbal
Stabilization
2-axis mechanical (tilt, roll)
Mechanical Range
Tilt: -125° to 105°
Roll: -43° to 43°
Controllable Range
Tilt: -90° to 70°
Max Control Speed (Tilt)
100°/s
Angular Vibration Range
±0.01°
Image Roll Correction
Corrects roll in recorded footage
(Live view correction requires RC; not available when using goggles.)
Sensing System
Omnidirectional monocular vision + downward IR sensor + forward LiDAR.
Forward Sensing
Measurement: 0.5–10 m
Detection: 0.5–15 m
Max speed: ≤ 8 m/s
Backward Sensing
Detection: 0.5–15 m
Max speed: ≤ 8 m/s
Lateral Sensing
Detection: 0.5–15 m
Max speed: ≤ 8 m/s
Upward Sensing
Detection: 0.5–15 m
Max speed: ≤ 3 m/s
Downward Sensing
Detection: 0.5–15 m
Max speed: ≤ 3 m/s
Infrared Sensors
Forward LiDAR:
• Range: 0.3–8 m
• FOV: 60° × 60°
Downward IR:
• Range: 0.3–8 m
Operating Environment Requirements
Forward/Back/Left/Right/Upward:
• Clear patterns
• Lighting > 5 lux
Downward:
• Diffuse surfaces (>20% reflectivity)
• Lighting > 5 lux
Video Transmission System
Transmission System
Standard: Wi-Fi Video Transmission
Optional: DJI Neo 2 Digital Transceiver (O4)
Live View Quality
RC-N3: up to 1080p/60fps
Goggles N3: up to 1080p/60fps
Goggles 3: up to 1080p/100fps
(Remote controller or goggles required.)
Operating Frequency
2.400–2.4835 GHz
5.170–5.250 GHz
5.725–5.850 GHz
(Regional limits apply.)
Transmitter Power (EIRP)
2.4 GHz: <26 dBm FCC, <20 dBm CE
5.1 GHz: <23 dBm CE
5.8 GHz: <26 dBm FCC, <14 dBm CE, <26 dBm SRRC
Communication Bandwidth
Up to 60 MHz
Max Transmission Distance (Unobstructed, No Interference)
FCC: 10 km
CE/SRRC/MIC: 6 km
Max Transmission Distance (Unobstructed, With Interference)
Strong: 1.5–3 km
Medium: 3–6 km
Low: 6–10 km
Max Transmission Distance (Obstructed)
Buildings: 0–0.5 km
Trees: 0.5–3 km
Max Download Speed
Wi-Fi: up to 80 MB/s
Lowest Latency
RC-N3 / RC 2: approx. 120 ms
Goggles N3 (1080p/60fps): ~54 ms
Goggles 3 (1080p/100fps): ~50 ms
Max Video Bitrate
60 Mbps
Antenna System
2 antennas, 1T2R
Wi-Fi
Protocols
802.11 a/b/g/n/ac/ax
Operating Frequency
2.400–2.4835 GHz
5.725–5.850 GHz
EIRP
2.4 GHz: <20 dBm
5.8 GHz: <26 dBm FCC/SRRC, <14 dBm CE
Effective Operating Range
Up to 500 m
(Tested under ideal FCC conditions.)
Bluetooth
Protocol
Bluetooth 5.2
Frequency
2.400–2.4835 GHz
(Regional variations apply.)
Transmitter Power (EIRP)
< 10 dBm
Battery
Capacity
1606 mAh
Weight
46 g
Nominal Voltage
7.16 V
Max Charging Voltage
8.6 V
Battery Type
Li-ion
Chemical System
LiNiMnCoO₂
Energy
11.5 Wh
Charging Temperature
5° to 40° C (41° to 104° F)
Charging Time
Using Two-Way Charging Hub (65W): ~68 minutes for three batteries
Charging through aircraft (15W): ~70 minutes
(Charging times tested at 25°C.)
Charger
Recommended Chargers
DJI 65W Portable Charger
USB Power Delivery chargers
Battery Charging Hub
Input
5 V up to 5 A
9 V up to 5 A
12 V up to 5 A
15 V up to 4.33 A
20 V up to 3.25 A
(Max current depends on adapter capacity.)
Output (Charging)
5 V, 2 A
Charging Method
Can charge up to 3 batteries simultaneously
(Requires charger ≥45W for simultaneous charging.)
Compatibility
DJI Neo 2 Intelligent Flight Battery
Storage
This aircraft does not support microSD card expansion.
DJI RC-N3 Remote Controller
Max Operating Time
3.5 hours (without charging a device)
1.5 hours (charging a mobile device)
Operating Temperature
-10° to 40° C
Charging Temperature
5° to 40° C
Charging Time
Approx. 2 hours (5V/2A)
Battery Capacity
2600 mAh
Weight
Approx. 320 g
Dimensions
104.2 × 150 × 45.2 mm
Supported Transmission Frequencies
2.400–2.4835 GHz
5.170–5.250 GHz
5.725–5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <33 dBm FCC, <20 dBm CE
5.1 GHz: <23 dBm CE
5.8 GHz: <33 dBm FCC, <14 dBm CE, <30 dBm SRRC
