DJI Mini 5 Pro – Full Specifications
Aircraft
Takeoff Weight
249.9 g
(Product weight may vary ±4 g depending on materials and batch. Check local regulations regarding registration or exam requirements when using the Intelligent Flight Battery Plus.)
Dimensions
- Folded (without propellers): 157 × 95 × 68 mm
- Unfolded (with propellers): 304 × 380 × 91 mm
Max Ascent Speed
- 10 m/s (S Mode)
- 5 m/s (N Mode)
- 5 m/s (C Mode)
Max Descent Speed
- 8 m/s (S Mode, Battery Plus)
- 6 m/s (S Mode, Standard Battery)
- 5 m/s (N Mode)
- 5 m/s (C Mode)
Max Horizontal Speed
- 19 m/s (S Mode, Battery Plus)
- 18 m/s (S Mode, Standard Battery)
- 15 m/s (Tracking Mode)
(Speed measured in controlled test conditions.)
Max Takeoff Altitude
- 6000 m (Standard Battery)
- 4500 m (Battery Plus)
Max Flight Time
- 36 minutes (Standard Battery)
- 52 minutes (Battery Plus)
Typical Flight Time
- 21 minutes (Standard Battery)
- 33 minutes (Battery Plus)
(Measured during realistic mixed-use flights at sea level.)
Max Flight Distance
- 21 km (Standard Battery)
- 32 km (Battery Plus)
Max Wind Resistance
12 m/s
Max Pitch Angle
38°
Operating Temperature
-10° to 40° C (14° to 104° F)
GNSS
GPS + Galileo + BeiDou
Hovering Accuracy
Vertical: ±0.1 m (vision), ±0.5 m (GNSS)
Horizontal: ±0.3 m (vision), ±0.5 m (GNSS)
Internal Storage
42 GB
Class
C0 (EU)
Camera
Image Sensor
1-inch CMOS, 50 MP effective
Lens
FOV 84°
24 mm equivalent
Aperture f/1.8
Focus range 0.5 m to ∞
ISO Range – Video
Normal: 100–12800
D-Log M: 100–3200
HLG: 100–3200
Slow Motion:
• Normal: 100–6400
• D-Log M: 100–3200
• HLG: 100–3200
ISO Range – Photo
12 MP: 100–6400
50 MP: 100–3200
Shutter Speed
12 MP: 1/8000–2 s (2.5–8 s for simulated long exposures)
50 MP: 1/8000–2 s
Max Photo Resolution
8192 × 6144
Still Photography Modes
Single Shot (12 MP, 50 MP)
Burst (12 MP: 3/5/7 frames)
Burst (50 MP: 3/5 frames)
AEB (12 MP: 3/5/7 frames)
AEB (50 MP: 3/5 frames at 0.7 EV)
Timed Capture (2–60 s depending on mode)
Photo Formats
JPEG / DNG (RAW)
Video Resolution & Framerates
4K (3840×2160): 24/25/30/48/50/60/120 fps
FHD (1920×1080): 24/25/30/48/50/60/120/240 fps
(Slow-motion recordings play back at lower encapsulated frame rates.)
Video Format
MP4 (H.264 / H.265)
Max Video Bitrate
Up to 130 Mbps (depending on mode and frame rate)
File System
exFAT
Color Profiles
Normal (FHD): 8-bit 4:2:0 (H.264)
Normal (FHD/4K): 10-bit 4:2:0 (H.265)
D-Log M / HLG: 10-bit 4:2:0 (H.265)
Digital Zoom
12 MP photos: 1–3×
4K video: 1–3×
FHD video: 1–4×
Gimbal
Stabilization
3-axis mechanical (tilt, roll, pan)
Mechanical Range
Tilt: -135° to 80°
Roll: -230° to 95°
Pan: -25° to 25°
Controllable Range
Tilt: -90° to 55°
Roll: -180° to 45°
Max Control Speed (Tilt)
100°/s
Angular Vibration Range
±0.005°
Sensing System
Omnidirectional binocular vision system + forward LiDAR + infrared sensors.
Forward Sensors
Measurement: 0.5–18 m
Detection: 0.5–200 m
Effective speed: ≤ 15 m/s
FOV: 90° horizontal, 72° vertical
Backward Sensors
Measurement: 0.5–18 m
Effective speed: ≤ 14 m/s
FOV: 90° horizontal, 72° vertical
Lateral Sensors
Measurement: 0.5–12 m
Effective speed: ≤ 14 m/s
FOV: 90° horizontal, 72° vertical
Upward Sensors
Measurement: 0.5–18 m
Effective speed: ≤ 6 m/s
FOV: 72° front/back, 90° left/right
Downward Sensors
Measurement: 0.3–14 m
Effective speed: ≤ 6 m/s
FOV: 106° front/back, 90° left/right
Operating Environment Requirements
Forward/Back/Left/Right/Upward:
Surfaces with clear patterns, adequate lighting (>1 lux)
Downward:
Surfaces with clear patterns, diffuse reflectivity >20%, adequate lighting
3D Infrared Sensor (LiDAR)
Forward LiDAR:
• Range (night): 0.5–25 m
• FOV: 60° up/down, 60° left/right
Downward Infrared:
• Range: 0.3–8 m
• FOV: 60° × 60°
Video Transmission (O4+)
Live View Quality
1080p/30fps or 1080p/60fps
Operating Frequencies
2.400–2.4835 GHz
5.170–5.250 GHz
5.725–5.850 GHz
(Availability varies by region.)
EIRP (Transmitter Power)
2.4 GHz: <33 dBm FCC, <20 dBm CE
5.1 GHz: <23 dBm CE
5.8 GHz: <33 dBm FCC, <14 dBm CE, <30 dBm SRRC
Max Transmission Distance (unobstructed)
20 km (FCC)
10 km (CE/SRRC/MIC)
With Interference (unobstructed)
Strong interference (urban): 1.5–4 km
Medium interference (suburban): 4–10 km
Low interference (seaside): 10–20 km
Obstructed (low interference)
0–0.7 km (buildings)
0.7–4.5 km (trees)
Max Download Speed
O4+: 10 MB/s
Wi-Fi 6: up to 100 MB/s
Lowest Latency
Approx. 120 ms (depends on environment)
Antenna System
4 antennas, 2T4R
Wi-Fi
Protocol
802.11 a/b/g/n/ac/ax
Operating Frequencies
2.400–2.4835 GHz
5.725–5.850 GHz
EIRP
2.4 GHz: <20 dBm
5.8 GHz: <26 dBm FCC/SRRC, <14 dBm CE
Bluetooth
Bluetooth 5.4
Operating band: 2.400–2.4835 GHz
Power: <10 dBm
Battery
Capacity
- Standard: 2788 mAh
- Battery Plus: 4680 mAh
Weight
- Standard: ~71.2 g
- Battery Plus: ~117 g
Voltage
- Standard: 7 V
- Plus: 7.16 V
Max Charging Voltage
8.6 V (both versions)
Type
Li-ion (LiNiMnCoO₂)
Energy
- Standard: 19.52 Wh
- Plus: 33.51 Wh
Charging Temperature
5° to 40° C
Charging Time (Standard Battery)
Through drone: ~69 min
Two-Way Hub: ~46 min
Three batteries via Hub: ~115 min
Charging Time (Battery Plus)
Through drone: ~94 min
Two-Way Hub: ~56 min
Three batteries via Hub: ~193 min
Battery Charging Hub
Input
USB-C: 5–15 V, max 4.3 A
Output
Battery ports: 5–15 V, max 2 A
Charging Method
Standard Battery: 2 batteries in parallel
Battery Plus: 3 batteries sequentially
Storage & Media
Recommended microSD Cards
Lexar Silver Plus: 64GB / 128GB / 256GB / 512GB / 1TB
Kingston Canvas Go! Plus: 64GB / 128GB / 256GB / 512GB
DJI RC-N3 Controller
Max Operating Time
3.5 hours (no phone charging)
1.5 hours (while charging phone)
Supported Device Size
180 × 86 × 10 mm
Operating Temperature
-10° to 40° C
Charging Temperature
5° to 40° C
Charging Time
Approx. 2 hours (recommended 5V/2A)
Battery Capacity
9.36 Wh (2600 mAh, 3.6 V)
Controller Weight
~320 g
Dimensions
104.2 × 150 × 45.2 mm
Phone Port Compatibility
Lightning, USB-C, Micro-USB
(Micro-USB cable sold separately.)
Transmission Frequency Support
2.400–2.4835 GHz
5.170–5.250 GHz
5.725–5.850 GHz
EIRP
2.4 GHz: <33 dBm FCC, <20 dBm CE
5.1 GHz: <23 dBm CE
5.8 GHz: <33 dBm FCC, <14 dBm CE, <30 dBm SRRC
